Visualizing Multidimensional Distributional data: some new tools

Once we were satisfied

Antonio Irpino, Ph.D.

Dept. of Mathematics and Physics
University of Campania L. Vanvitelli
Caserta, Italy

Tuesday, the 26^th of March, 2024

Motivations

(From “The grammar of graphics”, L. Wilkinsons)

Mathematics provides symbolic tools for representing abstractions.

Aesthetics, in the original Greek sense, offers principles for relating sensory attributes (color, shape, sound, etc.) to abstractions.

Data visualization and statistics

Statistics is the science of variability. Statistics aims at

describing,
measuring and
modeling

variability.

Data visualization, but, in particular, Statistical graphics is fundamental in describing variability at the different steps of a statistical analysis,

from the data preprocessing step,
passing through the summarization of raw and processed data
up to the representation of model validation.

For the analysis of aggregate or symbolic or distributional data or macrodata, there is a lack of visualization tools because of the complexity of the information there contained.

Aims

We propose new visualization tools for Macro data described as distributional data.

Starting from a data table where each macro unit can be described by several distributional variables, we propose

How to visualize a single macrodata or compare few of them, through eye iris or flowers plots;
How to visualizing large distributional data tables, extending the classic heatmap to the distributional heatmap.

An application to EUSILC data 2013 is presented for showing how to visually identify patterns in a distributional data table.

Macro data and distributional data: numeric distributional data

Let’s see an example: BLOOD dataset from the HistDAWass R package.

It is a classical (in the Symbolic Data Analysis community) dataset describing

14 typologies of patients;
3 distributional variables;

after aggregating a set of raw data from a hospital. See: Billard and Diday (2006)

	Cholesterol		Hemoglobin		Hematocrit
name	V1 bins	p1	V2 bins	p2	V3 bins	p3
	[80 ; 100]	0.025	[12 ; 12.9]	0.050	[35 ; 37.5]	0.025
	[100 ; 120]	0.075	[12.9 ; 13.2]	0.112	[37.5 ; 39]	0.075
	[120 ; 135]	0.175	[13.2 ; 13.5]	0.212	[39 ; 40.5]	0.188
u1: F-20	[135 ; 150]	0.250	[13.5 ; 13.8]	0.201	[40.5 ; 42]	0.387
	[150 ; 165]	0.200	[13.8 ; 14.1]	0.188	[42 ; 45.5]	0.287
	[165 ; 180]	0.162	[14.1 ; 14.4]	0.137	[45.5 ; 47]	0.038
	[180 ; 200]	0.088	[14.4 ; 14.7]	0.075
	[200 ; 240]	0.025	[14.7 ; 15]	0.025
	[80 ; 100]	0.013	[10.5 ; 11]	0.007	[31 ; 33]	0.046
	[100 ; 120]	0.088	[11 ; 11.3]	0.039	[33 ; 35]	0.171
	[120 ; 135]	0.154	[11.3 ; 11.6]	0.082	[35 ; 36.5]	0.295
	[135 ; 150]	0.253	[11.6 ; 11.9]	0.174	[36.5 ; 38]	0.243
u2: F-30	[150 ; 165]	0.210	[11.9 ; 12.2]	0.216	[38 ; 39.5]	0.170
	[165 ; 180]	0.177	[12.2 ; 12.5]	0.266	[39.5 ; 41]	0.072
	[180 ; 195]	0.066	[12.5 ; 12.8]	0.157	[41 ; 44]	0.003
	[195 ; 210]	0.026	[12.8 ; 14]	0.059
	[210 ; 240]	0.013
	[155 ; 170]	0.067	[10.8 ; 11.2]	0.133	[33.5 ; 35.5]	0.133
	[170 ; 185]	0.133	[11.2 ; 11.6]	0.067	[35.5 ; 37.5]	0.267
	[185 ; 200]	0.200	[11.6 ; 12]	0.134	[37.5 ; 39.5]	0.267
u14: M-80+	[200 ; 215]	0.267	[12 ; 12.4]	0.333	[39.5 ; 41.5]	0.133
	[215 ; 230]	0.200	[12.4 ; 12.8]	0.200	[41.5 ; 43]	0.200
	[230 ; 245]	0.067	[12.8 ; 13.2]	0.133
	[245 ; 260]	0.066

The first two and the last typology of patient in the BLOOD dataset.

Numerical distributional dataset

A distributional dataset is a classical table with \(N\) observations on the rows and \(P\) variables, indexing the columns, such that the generic term \(y_{ij}\) is a numerical univariate distribution

\[y_{ij}\sim f_{ij}(x_j)\] where \(x_j\in D_j \subset \Re\) and \(f_{ij}(x_j)\geq 0\),

\(\int\limits_{x_j \subset D_j}f_{ij}(x_j)dx_{j}=1\), if the distribution has a continuous support;
\(\sum\limits_{x_j\in D_j}{ f_{ij}(x_j)}=1\), if the distribution has a discrete support.

The basic plot for the \(i\)-th observation

The \(i\)-th observation is the vector \(y_i=[y_{i1},\ldots,y_{ij},\dots,y_{iP}]\)

Steps :

Domain discretization
- For continuous variables. For each variable \(Y_j\) we consider the domain \(D_j\) and, fixing a \(K_j\) integer value we partition \(D_j\) into \(K_j\) equi-width intervals (bins) of values, such that: \[D_j=\left\{ B_{jk}=(a_k,b_k], \lvert \, b_k>a_k,\, k=1,\ldots,K_j\, , \bigcup_{k=1}^KB_{jk}=[\min(D_j),\max(D_j)],B_{jk}\cap B_{jk'}=\emptyset, \text{ for } k\neq k' \right\} \]
- For discete variables. For each variable \(Y_j\) we consider the domain \(D_j\) and, being \(\# D_j=K_j\) the cardinality of \(D_j\), we consider the elements of \(D_j\).
Choice of a divergent colour palette_ We consider a divergent color palette with \(K_j\) levels, such that \(K_1\) represent the lowest category and \(K_j\) the highest one.
Stacked percentage barcharts We compute the mass observed in each bin/category for each \(y_{ij}\)
For the \(Y_i\) observation, \(P\) bars are generated. The order of the bar can be decided accordingly to the user preferences, or can be suggested by a correlation analysis for all the data in advance (one may cluster the distributional variables using a hierarchical clustering based on the Wasserstein correlation and then using the order returned by after the aggregation).
Polar coordinates Polar coordinates allow to represent the stacked barcharts as circles that mimics an Eye Iris.
We called this plot Eye Iris plot (EI plot.)

Example using BLOOD data

The extremes of the domains of the variables

Range of Cholesterol [ 80 ; 270 ]
Range of Hemoglobin [ 10.2 ; 15 ]
Range of Hematocrit [ 30 ; 47 ]

Choice of \(K\) and of a color palette

We fix \(K=50\) and we will use a color palette from Red (low values), passing through Yellow (middle values) to Green (high values).

Now, let’s take the first observation

Recode the distribution according to \(K=50\) partition of the domains.

Since the bins represent classes of values, we can consider them as ranked levels of the domain.

We propose to see all the three distributions using a stacked percentage barchart as follows. Note that each level of color has a area that is proportional to the mass associated with each bin.

The dashed line is positioned at level \(0.5\) suggesting where the median of each distribution is positioned taking into consideration the level of color associated with the bin of the respective domain.

But, this kind of visualization is not so immediate for comparing several observations. Let’s see an example:

We propose to use a plot based on polar coordinates. We add a pupil for reducing the distortion due to the polar transformation

Eye iris plot grammar

Each sector represents a distribution
Abundance of color
- towards the red = the distribution is concentrated on low values of the domain
- towards the green = the distribution is concentrated on high values of the domain

the dotted circle represents the level 0.5 of the CDFs, then the color close to it represents the median value of the distribution.
The more the colors of a sector are uniformly distributed the more the distribution is flat.

Since a human is able to catch eyes shapes and color, we believe that this kind of visualization can be more interpretable. For example, let’s see all the 14 observations together.

Interpretation

According to the filling colours we can compare both observations and distributional values.

The Enriched plot

We propose to add information about dispersion and skewness.

The dispersion

Each variable in the dataset may have a different dispersion. Each distributional variable has its dispersion accounted by its proper standard deviation \(\sigma_{ij}\). We normalize each standard deviation \(\sigma_{ij}\) by the maximum standard deviation of observed for the the \(j\)-th variable \(\max(\sigma_{ij})\) where \(i=1,\ldots,N\). A segment, centered in the respective sector, allow to perceive the dispersion associated with each distribution.

The skewness

Each \(y_{ij}\) has its skewness value computed via the Third standardized moment \(\gamma_{ij}\).

We represent the skewness of \(y_{ij}\) external to the dashed circle if it is positive, while it is positioned internally if it is negative. The distance from the dashed circle represent the absolute value of the skewness index. If the segment is very close to the dashed circle, it means that the distribution is almost symmetric.

An example applied to

Hierarchical clustering

Principal Component Analysis

Visualizing all the data table

A distributional heatmap

The EI plots can be useful for medium-sized data tables: less than 20 units or variables.

In any case, in this slides we present an alternative represantation of the BLOOD dataset by adapting the classical heatmap plot to distributional data.

In distributional heatmaps each tile contains a visualization of a row-column distribution.

The novelty

We substitute a single tile using horizontal stacked percentage bars that are constructed after binning each variable’s domain and using a diverging color palette, like for the EI plot.

A comparison between

Classical visualization

Distributional heatmap (new!!)

Advantages of heatmaps

Clustering rows

Clustering columns

Advantages of heatmaps, clustering both

An application to EUSILC 2013 survey

Data come from EUSILC survey (EU Statistics on Income and Living Conditions)

We downloaded the raw public available microdata from https://ec.europa.eu/eurostat/web/microdata/public-microdata/statistics-on-income-and-living-conditions

The website contains the EUSILC data for 2013 about 24 European countries.

number of cases 390,658 individuals
number of variables 285

We grouped the cases according to the

Country (24 countries),
Gender (Male and Female) and
Age class (4 classes)
- 15-24 y.o. (EARLY working age),
- 25-54 years (PRIME working age),
- 55-64 years (MATURE working age),
- 65 years and over (ELDER)

obtaining 192 groups (Macrounits). Each group is described by 20 distributional variables obtained from (Likert-type) items related to “satisfaction”.

Dictionary of variables

PW010: OVERALL LIFE SATISFACTION (0-10)
PW020: MEANING OF LIFE (0-10)
PW030: SATISFACTION WITH FINANCIAL SITUATION (0-10)
PW040: SATISFACTION WITH ACCOMMODATION (0-10)
PW050: BEING VERY NERVOUS (1-5 rev)
PW060: FEELING DOWN IN THE DUMPS (1-5)
PW070: FEELING CALM AND PEACEFUL (1-5 rev)
PW080: FEELING DOWNHEARTED OR DEPRESSED (1-5)
PW090: BEING HAPPY (1-5)
PW100: JOB SATISFACTION (0-10)
PW110: SATISFACTION WITH COMMUTING TIME (0-10)
PW120: SATISFACTION WITH TIME USE (0-10)

PW130: TRUST IN THE POLITICAL SYSTEM (0-10)
PW140: TRUST IN THE LEGAL SYSTEM (0-10)
PW150: TRUST IN THE POLICE (0-10)
PW160: SATISFACTION WITH PERSONAL RELATIONSHIPS (0-10)
PW190: TRUST IN OTHERS (0-10)
PW200: SATISFACTION WITH RECREATIONAL OR GREEN AREAS (0-10)
PW210: SATISFACTION WITH LIVING ENVIRONMENT (0-10)
PW220: PHYSICAL SECURITY (0-10)

The classical (useless) visualization (each cell is a barchart)

Comparing units: the Eye iris plot

Let’s observe eight eyes:

A new plot the Flower plot

In this plot each main direction is a variable and each petal is proportional to the relative frequency, the filling color is related to the value of the domain.

A problem: How to arrange the sectors for a better view?

We propose to sort variables according to an Hamiltonian cycle and to a the Traveling Salesman Problem.

The problem assumes a network where nodes are the variables and the links are weighted by the correlation distance: \[d(X_1,X_2)=\sqrt{2\left[1-Corr(X_1,X_2)\right]}\]

Comparing them

Looking all the units and all the variables: The distributional heatmap

Conclusions

We introduced new visualization tools for data tables of macrodata described by numeric distributions.
The Green Eye Iris plot and the Flower plot allow to compare few macrodata.
The Distributional Heatmap is a useful tool for moderate to big sized table.

… for the future …

Macrodata can be described by categoracal distributions, and, as for the classic tables, effective visualization tools needs to be developed.
The perception of differences between distributions is, indeed, difficult to visualize when the size of data increases both either in the number of individuals or the variables.
Visualizations tools able to translate statistical measures and concepts needs to be developed.

References

Billard, L., and E. Diday. 2006. Symbolic Data Analysis: Conceptual Statistics and Data Mining. Wiley.

Brito, P., and S. Dias. 2022. Analysis of Distributional Data. Chapman; Hall/CRC. https://doi.org/https://doi.org/10.1201/9781315370545.

Irpino, A. 2018. HistDAWass: Histogram Data Analysis Using Wasserstein Distance.

Irpino, A., and E. Romano. 2007. “Optimal Histogram Representation of Large Data Sets: Fisher Vs Piecewise Linear Approximation.” Revue Des Nouvelles Technologies de l’Information RNTI-E-9: 99–110.

Irpino, A., and R. Verde. 2006. “A New Wasserstein Based Distance for the Hierarchical Clustering of Histogram Symbolic Data.” In Data Science and Classification, edited by V. et al. Batagelj, 185–92. Berlin: Springer.

———. 2015. “Basic Statistics for Distributional Symbolic Variables: A New Metric-Based Approach.” Advances in Data Analysis and Classification 9 (2): 143–75.

Verde, R., and A. Irpino. 2018. “Multiple Factor Analysis of Distributional Data.” Statistica Applicata, Italin Journal of Applied Statistics.
